tempo · key · waveform

trail mix

trail mix is an offline audio-analysis toolkit written in Rust. It takes normalized mono PCM and returns tempo, musical key, beat positions, and compact waveform data. Analysis runs locally.

Cueport plans to use trail mix for local waveform and audio-analysis features, but the crates are built for any desktop, mobile, server, or research tool that needs this function.

An illustrated mix of nuts, seeds, raisins, and chocolate

Structure

  • beat salad estimates global BPM, beat positions with downbeat inference, and local tempo segments. Uses autocorrelation with harmonic scoring and a gentle octave prior.
  • key lime estimates global and local major or minor keys using dual chroma extraction (Goertzel + Constant-Q Transform), multiple key profiles (Krumhansl-Kessler, Temperley, EDMA, and learned), median aggregation, and confidence-gated segmentation.
  • sampler platter generates compact min/max/RMS waveform columns.

The trailmix crate combines the three analyzers behind one PCM-in/results-out API. File decoding is kept in the optional trailmix-codecs crate.

Supporting crates:

  • trailmix-cli: command-line analysis of individual files.
  • trailmix-bench: machine-readable benchmark reports (MIREX-weighted key score, beat F1, Serato agreement, timing).
  • trailmix-manifest: shared corpus annotation schema.
  • trailmix-datasets: imports GiantSteps reference annotations.
  • test-kitchen: loopback browser UI for playback, annotation, and on-demand analysis.

Quick start

trail mix requires Rust 1.85 or newer. To try the CLI from the repository root:

cargo run -p trailmix-cli -- path/to/audio.flac

The CLI supports MP3, FLAC, AIFF, WAV, AAC-in-MP4, and ALAC-in-MP4 and prints versioned analysis results as JSON. CI tests Linux, macOS, and Windows.

Design principles

  • Pure Rust, zero ML dependencies: all analysis is deterministic DSP.
  • Small binary: all three analyzers fit in under 3 MB.
  • Portable: runs on ARM, x86, and WASM without platform-specific inference machinery.
  • Interpretable: intermediate features (chroma vectors, onset envelopes, confidence scores) are exposed, not hidden in a black box.

Accuracy context

trail mix uses heuristic DSP, not trained models. Accuracy is below ML-based systems (CNN/transformer SOTA reaches ~73-78% key accuracy on GiantSteps). The tradeoff is explicit: lower accuracy in exchange for zero deployment complexity, no model downloads, and full algorithmic transparency.

See architecture for algorithm descriptions and design rationale.
